Laminate Quad Lockers

• Multiple color door order forms make it easy to mix and match door colors
• Additional shelves are available for order
• Quad lockers do not include shelves. If desired, adjustable shelves may be ordered separately
• Each locker compartment includes (2) two-pronged coat hooks, one per side
• The four locker doors are keyed randomly in the factory
• The four locker doors hinge together, either left or right

• Choose from keyed locks, electronic locks, or hasp locks
• Peel-and-stick door number plates .030 acrylic 1″ h x 2″w, surface color in brushed aluminum imprinted in black with any combination of numbers needed to permanently identify individual locker doors
• Common laminate tops
• Locker ganging kit, for ganging lockers side-to-side

• A 12 year warranty ensures long-lasting performance and after-sale support
• Leveling glides allow for 7/8” adjustment and are accessible from inside the locker

• Lockers come standard with randomly assigned UM Series lockers (#226-425).
• UM locks are black-faced, master-keyed and core-removable
• You may arrange with Customer Service to have these locks keyed-alike in the field
• Other key series options are available, including bright nickel LL, Haworth SL

• Hasp locks may be used instead of a keyed or electronic lock
• To order, specify “Hasp Lock” in the product description on your purchase order and add $50 list per door to the keyed locker price

E-Lock (E)

• Durable and versatile, electronic locks may be programmed to either fixed or revolving mode
• Once a code is entered, the lock is activated by turning the lever to the locked or unlocked position
• Runs on (2) AAA batteries (included)
• Operates using a 4-to-8 digit code
• A supervisor code is included – For large projects, the supervisor code may be pre-programmed into the locks
• Includes programmable reset features
• Easy to clean membrane keypad
• 75,000 plus cycles; extended battery life reduces replacement and labor maintenance costs
• 1 year warranty

E-Lock Mini Keypad (VM)

• Keypad operation
• Cam locking mechanism
• Manage with electronic keys
• Dual functionality – shared or assigned use
• Management override and power bypass
• All metal housing with brushed nickel finish
• Vertical orientation – knob on the top
• Visual and audible indicators
• Available with advanced features:  Mobile app management, Audit trail, Advanced auto unlock feature, Advanced system tools
• IP55 rated, FCC, CE, and CI certified , ADA compliant models available
• Powered by 2 lithium CR2032 batteries (included), Battery Life: 180,000 cycles with average use
• 2 year warranty

E-Lock Mini RFID (RM)

• Touch RFID operation
• RFID standards – iClass and Mifare (13.56 MHz) ISO 14443A, ISO 14443B, ISO 15693
• Cam locking mechanism
• Manage with electronic keys, shared or assigned use
• Management override and power bypass
• All metal housing with brushed nickel finish
• Vertical orientation knob on the top
• Visual and audible indicators
• Available with advanced features: Mobile app management, Audit trail, Advanced auto unlock feature, Advanced system tools
• IP55 rated, FCC, CE, and CI certified
• ADA compliant models available
• Powered by 4 premium AA batteries (included), Battery Life: 115,000 cycles with average use
• 2 year warranty

• Plug and play components
• Preconfigured kits for easy ordering
• 110v plug in feed for up to 8 lockers
• Total 25W power output
• Intelligent USB Type C with Power Delivery
• Reversible USB Type A with Fast Charge
• Internal overload protection
• LED Power Delivery indication
